Every cell you design is, by intent, isolated from every other cell. The one piece of the system that can’t fully follow that rule is the network path that decides which cell a piece of traffic reaches in the first place. Get the routing layer wrong and you’ve rebuilt the single point of failure you were trying to eliminate — just one layer higher up.

VPC topology: per-cell, shared, or AZ-as-boundary

There’s no single correct way to lay out VPCs against cells, and the right answer depends on which boundary you’re actually defending. A VPC per cell gives the cleanest isolation — a NACL misconfiguration or route table mistake in one VPC can’t reach another — but it multiplies NAT gateways, VPC endpoints, and IP address planning by the number of cells you run. A shared VPC with dedicated subnets per cell is cheaper to run and easier on IP address management, at the cost of some shared blast radius at the VPC level itself.

A third option skips the VPC question and uses the Availability Zone as the cell boundary directly. AWS’s own Journey to Cloud-Native architecture write-up describes exactly this: pods aligned into cell groups on EKS, spread across three AZs, with only the routing layer — Route 53, DynamoDB, and the load balancer — shared across the whole system. The payoff is concrete: without cells, an initial bad event could take out the entire application; spread across three AZ-aligned cells, the worst case for that same initial hit caps at roughly a third of total capacity.

Whether you also want an AWS account as an isolation boundary is a separate, harder call. Multiple accounts contain the damage from leaked credentials or an account hitting a service quota, but account sprawl brings its own tax — every account needs to be onboarded into billing, monitoring, and security tooling, and that overhead doesn’t disappear just because Organizations makes account creation easy.

Route 53 weighted routing, worked through

For AWS-native cell routing, Route 53 weighted routing does a lot of the heavy lifting cheaply. Each cell (or infra group within a cell) gets a weighted alias record behind one stable DNS name, and adding capacity is just adding another weighted record — existing clients never need a DNS change. A record for a new cell might look like this:

{
  "Action": "CREATE",
  "ResourceRecordSet": {
    "Name": "orders.us-east-1.example.com",
    "Type": "A",
    "SetIdentifier": "cell-04",
    "Weight": 50,
    "AliasTarget": {
      "HostedZoneId": "Z35SXDOTRQ7X7K",
      "DNSName": "cell-04-alb.us-east-1.elb.amazonaws.com",
      "EvaluateTargetHealth": true
    }
  }
}

Turning on health evaluation matters here — it’s what keeps Route 53 from sending traffic to a cell whose ALB has gone unhealthy. A hosted zone supports up to 10,000 weighted records, so this scales to a lot of cells before you need to think about it again.

The ALB quotas that quietly cap your design

Two unglamorous Application Load Balancer quotas end up shaping infra-group size before any architecture diagram does: a maximum of 100 target groups per load balancer, and a maximum of 5 target groups per listener rule. Work through the arithmetic and one ALB, configured with reasonably granular listener rules, comfortably serves on the order of 50 tenant or cell targets before you need a second ALB — which is exactly the trigger AWS Ads used to decide when to add a new infra group rather than scale the existing one vertically. Knowing this number before you design the routing layer saves a redesign later.

PrivateLink for shared dependencies — and its cost

Cells rarely live in complete isolation from the rest of your platform; they usually need to reach a handful of centrally-owned services — a shared cache, an identity provider, a billing system. AWS PrivateLink is the standard way to expose those without opening them to the public internet or wiring up VPC peering per cell. The trick that actually pays off is pre-wiring the interface endpoints once, at tier or platform creation time, rather than per tenant — AWS Ads reports an 80 percent cut in network configuration overhead from doing exactly that. Each interface endpoint runs a modest, predictable cost — roughly $7.30 a month plus data transfer — which is close to noise once it’s shared across dozens of cells, and a line item worth tracking once it’s multiplied per cell instead.

Where a Transit Gateway shows up to connect layers of cells to each other, treat it carefully. A single TGW sitting at the center of every cell-to-cell path becomes exactly the kind of shared point of failure the whole architecture was designed to avoid. If cross-layer traffic is limited to a small, known set of backend cells, bilateral connections are often the safer default over a hub-and-spoke TGW.

Where VPC Lattice fits

Amazon VPC Lattice is worth knowing about for the service-to-service leg of this problem specifically. It gives services a logical, IAM-authorized identity instead of an IP address, and it works across EC2, ECS, EKS, and Lambda targets in different accounts and VPCs without hand-built peering or Transit Gateway routes. That makes it a good fit for the case where a cell’s workloads need to reach a small set of centrally-owned services elsewhere in the organization — but it’s not a cell router. It solves reachability between services, not the “which cell does this customer belong to” assignment problem, which still needs the DynamoDB-and-DNS pattern from the routing layer.

Certificates: the boring single point of failure

One detail that’s easy to skip and expensive to skip: give each cell its own TLS certificate with its own expiration date rather than sharing one certificate estate-wide. A single shared certificate that expires or gets misconfigured is a shared blast radius, no different in kind from a shared VPC route table — it just doesn’t look like one until it fails.

Networking is the layer of a cell-based system you actually want to be a little boring — predictable quotas, pre-wired connectivity, health-checked routing, and nothing clever sitting in the critical path that doesn’t need to be there. Boring networking is what makes the resiliency claims in the next post actually hold up under a real failure, rather than just on the architecture diagram.
